Features: • Operates from single 3 V supply (LM311B)• Maximum input bias current: 150 nA (LM311: 250 nA)• Maximum offset current: 20 nA (LM311: 50 nA)• Differential input voltage range: ±30 V• Power consumption: 135 mW at ±15 V• High sensitivity: 200 V/mV•...
AU211: Features: • Operates from single 3 V supply (LM311B)• Maximum input bias current: 150 nA (LM311: 250 nA)• Maximum offset current: 20 nA (LM311: 50 nA)• Differential input vol...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
SYMBOL |
PARAMETER |
RATING |
UNIT | |
VS | Total supply voltage |
36 |
V | |
Output to negative supply voltage | LM111/LM211 |
50 |
V | |
LM311/LM311B |
40 |
V | ||
Ground to negative supply voltage |
30 |
V | ||
Differential input voltage |
±30 |
V | ||
VIN | Input voltage 1 |
±15 |
V | |
PD MAX | Maximum power dissipation, Tamb = 25 °C (still-air) 2 | N package |
1190 |
mW |
D package |
780 |
mW | ||
I | Output short-circuit duration |
10 |
sec | |
Tamb | Operating ambient temperature range | AU211 |
40 to +125 |
°C |
LM111 |
55 to +125 |
°C | ||
LM211 |
25 to +85 |
°C | ||
LM311/LM311B |
0 to +70 |
°C | ||
Tstg | Storage temperature range |
65 to +150 |
°C | |
Tsld | Lead soldering temperature (10 sec max) |
230 |
°C |
The AU211 series are voltage comparators that have input currents approximately a hundred times lower than devices like the µA710.They are designed to operate over a wider range of supply voltages;from standard ±15 V op amp supplies down to a single 3 V supply.Their output is compatible with RTL, DTL, and TTL as well as MOS circuits. Further, they can drive lamps or relays, switching voltages up to 50 V at currents as high as 50mA.
Both the inputs and the outputs of the AU211 series can be isolated from system ground, and the output can drive loads referred to ground, the positive supply, or the negative supply. Offset balancing and strobe capability are provided and outputs can be wire-ORed.
Although slower than the µA710 (200 ns response time versus 40 ns),the devices are also much less prone to spurious oscillations. The AU211 series has the same pin configuration as the µA710 series.
