AT45DB041D-SU

Data Bus Width :
Memory Type :
Timing Type :
Access Time :
Packaging :
Supply Voltage - Max : 3.6 V
Supply Voltage - Min : 2.7 V
Mounting Style : SMD/SMT
Interface Type : SPI
Architecture : Sectored
Maximum Operating Current : 15 mA
Package / Case : SOIC
Memory Size : 4 MB
Operating Temperature : + 125 C


Pinout




Description

The AT45DB041D-SU is one member of the AT45DB041D family which designed as one kind of 2.5V or 2.7V, serial-interface Flash memory ideally suited for a wide variety of digital voice-, image-, program code- and data-storage applications. AT45DB041D-SU also contains two SRAM buffers of 256/264 bytes each.The device operates from a single power supply, 2.5V to 3.6V or 2.7V to 3.6V, for both the program and read operations.

Features of the AT45DB041D-SU are:(1)single 2.5V or 2.7V to 3.6V supply;(2)rapidS® serial interface:66 MHz maximum clock frequency-SPI compatible modes 0 and 3;(3)user configurable page size:256 bytes per page or 264 bytes per page;(4)page program operation:intelligent programming operation and 2,048 pages (256/264 bytes/page) main memory;(5)flexible erase options:page erase (256 bytes),block erase (2 kbytes),sector erase (64 kbytes),chip erase (4 mbits);(6)two SRAM data buffers (256/264 bytes)- allows receiving of data while reprogramming the flash array;(7)continuous read capability through entire array-ideal for code shadowing applications;(8)low-power dissipation:7 mA active read current typical,25 A standby current typical,5 A deep power-down typical;(9)green (pb/halide-free/RoHS compliant) packaging options;(10)industrial temperature range;(11)data retention-20 years;(12)100,000 program/erase cycles per page minimum;(13)JEDEC standard manufacturer and device ID read.

The absolute maximum ratings of the AT45DB041D-SU can be summarized as:(1)temperature under bias:-55°C to +125°C;(2)storage temperature:-65°C to +150°C;(3)all input voltages (including NC pins) with respect to ground:-0.6V to +6.25V;(4)all output voltages with respect to ground:-0.6V to VCC+0.6V.If you want to know more information such as the electrical characteristics about the AT45DB041D-SU,please download the datasheet in www.seekic.com or www.chinaicmart.com .

Parameters:

Technical/Catalog Information	AT45DB041D-SU
Vendor	Atmel
Category	Integrated Circuits (ICs)
Memory Type	DataFLASH
Memory Size	4M (2048 pages x 264 bytes)
Speed	66MHz
Interface	SPI, RapidS
Package / Case	8-SOIC
Packaging	Tube
Voltage - Supply	2.7 V ~ 3.6 V
Operating Temperature	-40°C ~ 85°C
Format - Memory	FLASH
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	AT45DB041D SU AT45DB041DSU
