Maximum Operating Temperature
: + 85 C
Mounting Style
: SMD/SMT
Memory Size
: 4 Kbit
Package / Case
: TSSOP-8
Maximum Clock Frequency
: 0.4 MHz
Data Retention
: 100 Years
Operating Supply Voltage
: 2.5 V, 3.3 V, 5 V
Maximum Operating Current
: 3 mA
Organization
: 512 x 8
Pinout
DescriptionThe AT24C04B-TH-T has fourteen features.(1)low-voltage and standard-voltage operation 1.8 (VCC = 1.8V to 5.5V).(2)internally organized 512 x 8 (4K), or 1024 x 8 (8K).(3)two-wire serial interface.(4)schmitt trigger, filtered inputs for noise suppression.(5)bidirectional data transfer protocol.(6)1 MHz (5V), 400 kHz (1.8V, 2.5V, 2.7V) compatibility.(7)write protect pin for hardware and software data protection.(8)16-byte page (4K, 8K) write modes.(9)partial page writes allowed.(10)self-timed write cycle (5 ms max).(11)high-reliability.(12)8-lead JEDEC PDIP, 8-lead JEDEC SOIC, EIAJ SOIC, 8-lead ultra thin small array package (SAP), 8-lead TSSOP, and 8-ball dBGA2 packages.(13)lead-free/halogen-free.(14)die sales: wafer form, waffle pack, and bumped wafers.
The AT24C04B-TH-T provides 4096/8192 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 512/1024 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The AT24C04B-TH-T is available in space-saving 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead Ultra-Thin Mini-MAP (MLP 2x3), 5-lead SOT23, 8-lead TSSOP, and 8-ball dBGA2 packages and is accessed via a Two-wire serial interface. In addition, the AT24C08BN-SH-T is available in 1.8V (1.8V to 5.5V) version.
Parameters: | Technical/Catalog Information | AT24C04B-TH-T |
| Vendor | Atmel |
| Category | Integrated Circuits (ICs) |
| Memory Type | EEPROM |
| Memory Size | 4K (512 x 8) |
| Speed | 400kHz, 1MHz |
| Interface | I²C, 2-Wire Serial |
| Package / Case | 8-TSSOP |
| Packaging | Tape & Reel (TR) |
| Voltage - Supply | 1.8 V ~ 5.5 V |
| Operating Temperature | -40°C ~ 85°C |
| Format - Memory | EEPROMs - Serial |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | AT24C04B TH T
AT24C04BTHT
|
AT24C04B-TH-T Data Sheet
