AP60L02GS

Features: Low Gate Charge Simple Drive Requirement Fast SwitchingSpecifications Symbol Parameter Rating Units VDS Drain-Source Voltage 25 V VGS Gate-Source Voltage ±20 V ID@TC=25 Continuous Drain Current, VGS @ 10V 50 A ID@TC=100 Continuous Drain Current, VGS @ 1...

product image

AP60L02GS Picture
See larger image
SeekIC No. : 004286349 Detail

AP60L02GS: Features: Low Gate Charge Simple Drive Requirement Fast SwitchingSpecifications Symbol Parameter Rating Units VDS Drain-Source Voltage 25 V VGS Gate-Source Voltage ±20 V ...

AP60L02GS Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
AP60L02GS
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Low Gate Charge
Simple Drive Requirement
Fast Switching


Specifications

Symbol Parameter Rating Units
VDS Drain-Source Voltage 25 V
VGS Gate-Source Voltage ±20 V
ID@TC=25 Continuous Drain Current, VGS @ 10V 50 A
ID@TC=100 Continuous Drain Current, VGS @ 10V 32 A
IDM Pulsed Drain Current1 180 A
PD@TC=25 Total Power Dissipation 62.5 W/
  Linear Derating Factor 0.5 W
TSTG Storage Temperature Range -55 to 150
TJ Operating Junction Temperature Range -55 to 150



Description

The Advanced Power MOSFETs AP60L02GS from APEC provide the designer with the best combination of fast switching,ruggedized device design, low on-resistance and cost-effectiveness.

The TO-263 package is universally preferred for all commercialindustrial surface mount applications and suited for low voltage applications such as DC/DC converters. The through-hole version (AP60L02GS) is available for low-profile applications.
