The features of AP-10 are high output: + 22.0dBm, medium gain:+9.7dB, high third order IP: +34.0dBm typical, various package options (see photo)(surface mounted (SMTO-8), flatpack with flange connector zed connector zed flat pack(CFP), flat pack and TO-8 (AH)).
The maximum ratings of AP-10 are amtslent operating temperature(- 54 to + 85), storage temperature(- 62v to + 125), maximum case temperature(+95), maximum do voltage(+ 18.0V ), maximum continuous RF input power(+ 50.0 mW), maximum short term RF input power (+100.0mW (1 minute Max.)), maximum peak power (+0.5W (3seconds Max.)), series bum-in temperature(+ 85), weight(+ 2.5 grams Max. ).
Some electrical specifications of AP-10 are got in different temperature ranges, they are individually 25, 0 to +50 and -54 to +85.The details of it are frequency (MHz Min.)=10-1000/10-1000/10-1000, small signal gain (dB Min.)=+9.7/+9.5/+9.0, gain flatness(db max.)=±0.3/±0.7/±1.0, noise figure(db max.)=+8.0/+9.5/+10.0, power output @ 1 db compression (dBm min.)=+22.0/ +20.0/ + 20.0, one tone 2nd harmonic intercept point (dBm min.)=+58.0/+56.0/+ 50.0, input/output vswr(max.)=<1.8:1 1.9:1 2.0:1, dc current at 15v(ma max.)=+101/+106/+110.
