AOD486A

MOSFET N-CH 40V 50A TO-252

product image

AOD486A Picture
SeekIC No. : 003430949 Detail

AOD486A: MOSFET N-CH 40V 50A TO-252

floor Price/Ceiling Price

US $ .19~.49 / Piece | Get Latest Price
Part Number:
AOD486A
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • 250~500
  • 500~1000
  • Unit Price
  • $.49
  • $.38
  • $.33
  • $.29
  • $.24
  • $.19
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: - Manufacturer: Alpha & Omega Semiconductor Inc
FET Type: MOSFET N-Channel, Metal Oxide Transistor Type: -
Gain : 15.5 dB Current - Collector (Ic) (Max): -
FET Feature: Logic Level Gate Drain to Source Voltage (Vdss): 40V
Voltage - Collector Emitter Breakdown (Max): - Current - Continuous Drain (Id) @ 25° C: 50A
Vce Saturation (Max) @ Ib, Ic: - Current - Collector Cutoff (Max): -
Rds On (Max) @ Id, Vgs: 9.8 mOhm @ 20A, 10V DC Current Gain (hFE) (Min) @ Ic, Vce: -
Vgs(th) (Max) @ Id: 3V @ 250µA Gate Charge (Qg) @ Vgs: 22nC @ 10V
Frequency - Transition: - Input Capacitance (Ciss) @ Vds: 1920pF @ 20V
Power - Max: 50W Mounting Type: Surface Mount
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63 Supplier Device Package: TO-252, (D-Pak)

Description

Series: -
FET Type: MOSFET N-Channel, Metal Oxide
Transistor Type: -
Current - Collector (Ic) (Max): -
FET Feature: Logic Level Gate
Voltage - Collector Emitter Breakdown (Max): -
Vce Saturation (Max) @ Ib, Ic: -
Current - Collector Cutoff (Max): -
DC Current Gain (hFE) (Min) @ Ic, Vce: -
Vgs(th) (Max) @ Id: 3V @ 250µA
Frequency - Transition: -
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)Alternate Packaging
Drain to Source Voltage (Vdss): 40V
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Gate Charge (Qg) @ Vgs: 22nC @ 10V
Supplier Device Package: TO-252, (D-Pak)
Current - Continuous Drain (Id) @ 25° C: 50A
Power - Max: 50W
Manufacturer: Alpha & Omega Semiconductor Inc
Input Capacitance (Ciss) @ Vds: 1920pF @ 20V
Rds On (Max) @ Id, Vgs: 9.8 mOhm @ 20A, 10V


Parameters:

Technical/Catalog InformationAOD486A
VendorAlpha & Omega Semiconductor Inc (VA)
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET PolarityN-Channel
Drain to Source Voltage (Vdss)40V
Current - Continuous Drain (Id) @ 25° C50A
Rds On (Max) @ Id, Vgs9.8 mOhm @ 20A, 10V
Input Capacitance (Ciss) @ Vds 1920pF @ 20V
Power - Max50W
PackagingCut Tape (CT)
Gate Charge (Qg) @ Vgs22nC @ 10V
Package / CaseDPak,SC-63,TO-252 (2 leads+tab)
FET FeatureLogic Level Gate
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names AOD486A
AOD486A
785 1115 1 ND
78511151ND
785-1115-1
