AO4443

MOSFET P-CH 40V 6A 8SOIC

product image

AO4443 Picture
See larger image
SeekIC No. : 003430984 Detail

AO4443: MOSFET P-CH 40V 6A 8SOIC

AO4443 Data Sheet

floor Price/Ceiling Price

US $ .14~.14 / Piece | Get Latest Price
Part Number:
AO4443
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 0~3000
  • Unit Price
  • $.14
  • Processing time
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/22

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: - Manufacturer: Alpha & Omega Semiconductor Inc
FET Type: MOSFET P-Channel, Metal Oxide Transistor Type: -
Current - Collector (Ic) (Max): - FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 40V Continuous Drain Current : 15 A
Voltage - Collector Emitter Breakdown (Max): - Current - Continuous Drain (Id) @ 25° C: 6A
Vce Saturation (Max) @ Ib, Ic: - Current - Collector Cutoff (Max): -
Rds On (Max) @ Id, Vgs: 42 mOhm @ 6A, 10V DC Current Gain (hFE) (Min) @ Ic, Vce: -
Vgs(th) (Max) @ Id: 2.6V @ 250µA Gate Charge (Qg) @ Vgs: 22nC @ 10V
Frequency - Transition: - Input Capacitance (Ciss) @ Vds: 1175pF @ 20V
Power - Max: 3.1W Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.154", 3.90mm Width) Supplier Device Package: 8-SOIC

Description

Series: -
Transistor Type: -
Current - Collector (Ic) (Max): -
FET Feature: Logic Level Gate
Voltage - Collector Emitter Breakdown (Max): -
Vce Saturation (Max) @ Ib, Ic: -
Current - Collector Cutoff (Max): -
DC Current Gain (hFE) (Min) @ Ic, Vce: -
Frequency - Transition: -
Mounting Type: Surface Mount
FET Type: MOSFET P-Channel, Metal Oxide
Current - Continuous Drain (Id) @ 25° C: 6A
Packaging: Tape & Reel (TR)
Drain to Source Voltage (Vdss): 40V
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Power - Max: 3.1W
Gate Charge (Qg) @ Vgs: 22nC @ 10V
Vgs(th) (Max) @ Id: 2.6V @ 250µA
Supplier Device Package: 8-SOIC
Manufacturer: Alpha & Omega Semiconductor Inc
Rds On (Max) @ Id, Vgs: 42 mOhm @ 6A, 10V
Input Capacitance (Ciss) @ Vds: 1175pF @ 20V
