Product Details

Description



Features:

• 0.6 µm Drawn Gate Length (0.5 µm Leff) Sea-of-Gates Architecturewith Triple-level Metal
• 5.0V, 3.3V and 2.0V Operation including Mixed Voltages
• On-chip Phase Locked Loop Available to Synthesize Frequencies up to 150 MHz andManage Chip-to-Chip Clock Skew
• Compiled (Gate Level) and Embedded (Custom) SRAMs, ROM, and CAMs Available
• PCI, SCSI and High Speed (250 MHz) Buffers Available
• Easy Alternative Sourcing of Existing ASIC, FPGA and PLD Designs
• Design-for-Test Methods, Including JTAG, Serial and Boundary Scan and ATPG
• High Output Drive Capability: Up to 48 mA with Slew Rate Control


Specifications

Operating Temperature

−55°Cto+125°C

Storage Temperature

−65°Cto+150°C

Voltage on Any Pin with Respect to Ground

−2.0V to +7.0V(2)

Maximum Operating Voltage

6.0V




Description

Atmel's next generation ATL60 Series CMOS ASICs are fabricated using a 0.6µmdrawn gate, oxide isolated, triple-level metal process. Extensive cell libraries are avail-able and support the major CAD software tools. As with all Atmel ASIC families,customer involvement and satisfaction is integral to all steps of the design flow. A vari-ety of Design for Testability techniques are supported by the libraries, and a widerange of packaging options are available. The ALT40 version utilizes a fine pitch stag-gered row on bond pads to achieve the smallest die size possible for a given padcount. The ALT40 is only available in a limited number of PQFP packages.
