AK632128AW

The Accutek AK632128W SRAM Module consists of fast high performance SRAMs mounted on a low height, 64 pin SIM or ZIP PCB. The module utilizes four 32 pin 128K x 8 SRAMs in 300 mil SOJ  packages and four decoupling capacitors mounted on the front side of a printed circuit board.

The AK632128W  SRAMs used have common I/O functions and single output enable functions. Also, four separate chip select (CE) connections are used to independently enable the four bytes. The modules can be supplied in a variety of access time values from 7nSEC to 35nSEC in CMOS or BiCMOS technology.

The Accutek AK632128W module is designed to have a maximum seated height of 0.600 inch SIM or 0.520 inch ZIP to provide for the lowest height off the board. Each conforms to JEDEC-standard sizes and pin-out configurations. Using two pins for module denisty identification, PD0 and PD1, minimizes interchangeability and design considerations when changing from one module size to the other in customer applications.
