AK25HB120

Application

AC/DC motor drives
Heater controls
Light dimmers
Static switches




Specifications

Symbol	Item	Ratings		Unit
		AK25HB120	AK25HB160
VDRM	Repetitive Peak Off-State Voltage	1200	1600	V

Symbol	Item		Conditions	Ratings	Unit
IT(AV)	Average On-State Current		Single phase, half wave, 180°conduction, Tc:94	25	A
I T(RMS)	R.M.S. On-State Current		Tc:94	55	A
ITSM	Surge On-State Current		12cycle, 50Hz/60Hz, peak value, non-reqetitive	450/500	A
I2t	I2t		Value for one cycle of surge current	1000	A2S
PGM	Peak Gate Power Dissipation			10	W
P G(AV)	Average Gate Power Dissipation			1	W
IFGM	Peak Gate Current			3	A
VFGM	Peak Gate Voltage(Forward)			10	V
VRGM	Peak Gate Voltage(Reverse)			5	V
di/dt	Critical Rate of Rise of On-State Current		IG=100mA,Tj=25,VD=1/2VDRM,dIG/dt=0.1A/s	100	A/s
VISO	Isolation Breakdown Voltage (R.M.S.)		A.C. 1 minute	2500	V
Tj	Operating Junction Temperature			-40 to +125
Tstg	Storage Temperature			-40 to +125
	Mounting Torque	Mounting(M6)	Recommended Value 2.5-3.9(25-40)	4.7(48)	N･m (f･)
		Terminal(M5)	Recommended Value 1.5-2.5(15-25)	2.7(28)
	Mass		Typical Value	170	g

Description

Power ThyristorModule AK25HB series are designed for various rectifier circuits and power controls. For your circuit application. following internal connections and wide voltage ratings up to 1,600V are available, and electrically isolated mounting base make your mechanical design easy.
Isolated mounting base
IT_(AV)25A, IT_(RMS)55A, ITSM 500A
di/dt 100 A/s
dv/dt 500V/s
