AH-404

The AH-404/AH-464 is a kind of 10 to 400 MHz TO-12 cascadable amplifier which possesses the features of low cost, small size and output level at +15.5 dBm.

The electrical specifications of  AH-404/AH-464  are measured in a 50-ohm system at + 15Vdc nominal. And they are ordered as fowllowing: typical 25/ guaranteed 0 to +50/ specifications -54 to 85, which are frequency (MHz Min.)=10-400/10-400/10-400, small signal gain (dB Min.) + 10.8/+10.0/+9.0, gain flatness (dB Max.) ± 0.3/± 0.8/± 1.0, noise figure (dB Max.) +6.5/+7.0/+9.0, power output @ 1 dB compression (dBm Min.) +15.5/+15.0/+13.0, two tone 3rd order intercept point (dBm Min.) + 30.0/ +26.0/+23.0, two tone 2nd order intercept point (dBm Min.) + 37.0/+36.0/+33.0, one tone 2nd harmonic intercept point (dBm. Min.) 39.0/+42.0/+38.0, input/output VSWR 1.7:1/2.0:1/2.0:1, DO current at 15 (mA Max.) +58.0/+60.0/+70.0.

The maximum ratings of AH-404/AH-464 are ambient temperature -54 to 100, storage temperature -62 to 125, maximum case tempweature +100, maximum DC  voltage +18.0V, maximum continous RF input power +13.0dBm, maximum short term RF input power +50.0mW (1 minute max.), maximum peak power +0.5W (3seconds max.), weight +2.3 grams max.
