ADSP-2100

Features: ·25 MIPS, 40 ns Maximum Instruction Rate·Separate On-Chip Buses for Program and Data Memory·Program Memory Stores Both Instructions and Data (Three-Bus Performance)·Dual Data Address Generators with Modulo and Bit-Reverse Addressing·Efficient Program Sequencing with Zero-Overhead Looping...

product image

ADSP-2100 Picture
See larger image
SeekIC No. : 004277398 Detail

ADSP-2100: Features: ·25 MIPS, 40 ns Maximum Instruction Rate·Separate On-Chip Buses for Program and Data Memory·Program Memory Stores Both Instructions and Data (Three-Bus Performance)·Dual Data Address Gener...

ADSP-2100 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ADSP-2100
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·25 MIPS, 40 ns Maximum Instruction Rate
·Separate On-Chip Buses for Program and Data Memory
·Program Memory Stores Both Instructions and Data (Three-Bus Performance)
·Dual Data Address Generators with Modulo and Bit-Reverse Addressing
·Efficient Program Sequencing with Zero-Overhead Looping: Single-Cycle Loop Setup
·Automatic Booting of On-Chip Program Memory from Byte-Wide External Memory (e.g., EPROM )
·Double-Buffered Serial Ports with Companding Hardware, Automatic Data Buffering, and Multichannel ··Operation ADSP-2111 Host Interface Port Provides Easy Interface to 68000, 80C51, ADSP-21xx, Etc.
·Automatic Booting of ADSP-2111 Program Memory Through Host Interface Port
·Three Edge- or Level-Sensitive Interrupts
·Low Power IDLE Instruction
·PGA, PLCC, PQFP, and TQFP Packages
·MIL-STD-883B Versions Available


Specifications

Supply Voltage ..................0.3 V to +7 V
Input Voltage  .............. 0.3 V to VDD + 0.3 V
Output Voltage Swing...........0.3 V to VDD + 0.3 V
Operating Temperature Range (Ambient)...55ºC to +125ºC
Storage Temperature Range .........65ºC to +150ºC
Lead Temperature (10 sec) PGA.............+300ºC
Lead Temperature (5 sec) PLCC, PQFP, TQFP...... +280ºC

*Stresses greater than those listed above may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions greater than those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.


Description

The ADSP-2100 Family processors are single-chip microcomputers optimized for digital signal processing (DSP) and other high speed numeric processing applications. The ADSP-21xx processors are all built upon a common core. Each processor combines the core DSP architecture-computation units, data address generators, and program sequencer-with differentiating features such as on-chip program and data memory RAM, a programmable timer, one or two serial ports, and, on the ADSP-2100, a host interface port.
