ADS8472

`0 to 1-MHz Sample Rate
`±0.4 LSB Typ, ±0.65 LSB Max INL
`±0.3 LSB Typ, ±0.5 LSB Max DNL
`16-Bit NMC Ensured Over Temperature
`±0.1-mV Offset Error
`±0.05-PPM/°C Offset Error Drift
`±0.035 %FSR Gain Error
`±0.4-PPM/°C Gain Error Drift
`95dB SNR, -120dB THD, 123dB SFDR
`Zero Latency
`Low Power: 225 mW at 1 MSPS
`Unipolar Differential Input Range: Vref to Vref read cycles.
`Onboard Reference with 6 PPM/°C Drift
`Onboard Reference Buffer
`High-Speed Parallel Interface
`Wide Digital Supply 2.7 V to 5.25 V
`8-/16-Bit Bus Transfer
`48-Pin 7x7 QFN Package

The ADS8472 is an 16-bit, 1-MSPS A/C converterwith an internal 4.096-V reference and a pseudo-bipolar, fully differential input. The device includes a 16-bit capacitor-based SAR A/D converter with inherent sample and hold. The ADS8472 offers a full 16-bit interface or an 8-bit bus option using two  eadcycles.

The ADS8472 is available in a 48-lead 7x7 QFN package and is characterized over the industrial 40°C to 85°C temperature range.
