ADRF6701

The ADRF6701 is designed as one kind of highly integrated broadband quadrature demodulator, frequency synthesizer, and variable gain amplifier. And this device is available in a 40-lead, exposedpaddle, Pb-free, 6mm x 6mm LFCSP package. Performance is specified over a -40°C to +85°C temperature range.

Features of the ADRF6701 are:(1)IQ Modulator with Integrated Fractional-N PLL; (2)Output frequency range: 400 MHz to 1300 MHz; (3)Internal LO Frequency Range: 750 MHz to 1160 MHz; (4)Output P1dB: +14 dBm; (5)Output IP3: +29 dBm; (6)Noise Floor: -158 dBm/Hz; (7)Baseband Modulation bandwidth: 500 MHz (3 dB); (8)SPI Serial Interface for PLL Programing; (9)Power Supply: +5 V / 210 mA; (10)40 Pin 6mm X 6mm LFCSP.

The absolute maximum ratings of the ADRF6701 can be summarized as:(1)Storage Temperature Range: -65°C to +150°C;(2)Maximum Junction Temperature: 125°C;(3)JA (Exposed Paddle Soldered Down): 26°C/W;(4)RFI, RFI, RFCM: 0 V to 3.0 V;(5)Digital Input/Output: -0.3 V to +4.0 V;(6)Analog Input/Output: -0.3 V to +4.0 V;(7)Supply Voltage Pins: -0.3 V to +4.0 V.etc. If you want to know more information about the ADRF6701, please download the datasheet in www.seekic.com or www.chinaicmart.com .
