product image

ADP3806 Picture
See larger image
SeekIC No. : 004276724 Detail

ADP3806: Features: *Li-Ion Battery Charger*Three Battery Voltage Options Selectable 12.525 V/16.700 V Selectable 12.600 V/16.800 VAdjustable*High End-of-Charge Voltage Accuracy ±0.4% @ 25 ±0.6% @ 5Cto 55 ±0....

ADP3806 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ADP3806
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/7/15

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

*Li-Ion Battery Charger
*Three Battery Voltage Options
            Selectable 12.525 V/16.700 V
            Selectable 12.600 V/16.800 V
            Adjustable
*High End-of-Charge Voltage Accuracy
            ±0.4% @ 25
            ±0.6% @ 5Cto 55
            ±0.7% @ 0 to 85
*Programmable Charge Current with Rail-to-Rail Sensing
*System Current Sense with Reverse Input Protection
*Soft-Start Charge Current
*Undervoltage Lockout
*Bootstrapped Synchronous Drive for External NMOS
*Programmable Oscillator Frequency
*Oscillator SYNC Pin
*Low Current Flag
*Trickle Charge



Application

*Portable Computers
*Fast Chargers


Pinout

Connection Diagram


Specifications

Input Voltage (VCC) . . . . . . . . . . . . . . . . . . . . 0.3 V to +25 V
BAT, CS+, CS . . . . . . . . . . . . . . . . . . ..0.3 V to VCC + 0.3 V
SYS+, SYS . . . . . . . . . . . . . . . . . . . . . . . . . . .25 V to +25 V
BST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.3 V to +30 V
BST to SW . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3 V to +8 V
SW to PGND . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 V to +25 V
DRVL to PGND . . . . . . . . . . . . . . . . . . . . . . . . ..0.3 V to +8 V
ISET, BATSEL, SD, SYNC, CT,
LIMIT, ISYS, LC . . . . . . . . . . . . . . . . . . . . .. .. 0.3 V to +10 V
COMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3 V to +3 V
GND to PGND . . . . . . . . . . . . . . . . . . . . . . .. .0.3 V to +0.3 V
Operating Ambient Temperature Range . . . . . 0C to 100C
JA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115/W
Operating Junction Temperature Range . . . . . . 0C to 125
Storage Temperature Range . . . . . . . . . . . . 65 to +150
Lead Temperature Range (Soldering 10 sec) . . . . . . . . .300


Description

The ADP3806 is a complete Li-Ion battery-charging IC. The device combines high output voltage accuracy with constant current control to simplify the implementation of constant-current, constant-voltage (CCCV) chargers. The product is available in three options: The ADP3806-12.6 guarantees the final battery voltage selected is 12.6 V or 16.8 V ±0.6%, theADP3806-12.5 guarantees 12.525 V/16.7 V ±0.6%, and the product is adjustable using two external resistors to set the battery voltage. The current sense amplifier has rail-to-rail inputs to accurately operate under low dropout and short-circuit condi-tions. The charge current is programmable with a dc voltage on ISET. A second differential amplifier senses the system current across an external sense resistor and outputs a linear voltage on the ISYS pin. The bootstrapped synchronous driver allows the use of two NMOS transistors for lower system cost.
