Features: Four Operational Modes Including: Constant Laser Current Constant Optical Output Power Constant EDFA Gain Constant Laser Power High Power Efficiency: >90% Three Built-In Photodiode TIAs Adjustable Laser Diode and EDFA Protection Limits Free-run or Synchronous Switching Frequency Modes...
ADN8820*: Features: Four Operational Modes Including: Constant Laser Current Constant Optical Output Power Constant EDFA Gain Constant Laser Power High Power Efficiency: >90% Three Built-In Photodiode TIAs...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
The ADN8820 is a versatile Continuous Wave (CW) and EDFA laser diode driver and controller. ADN8820 provides a low noise and precise current control for driving a source or pump laser diode.The ADN8820 has a high speed closed-loop control, making it suitable for add/drop applications in telecommunication systems.
ADN8820 has a low-current shutdown mode and a soft-start feature to minimize power supply bounce on start-up. Protection circuitry is built into the device. The protection limits are easily adjustable and are used to set maximum output current and voltage, optical output power, EDFA gain, and pump or CW laser power.
The output stage consists of a high-efficiency PWM amplifier in parallel with a high-speed linear amplifier. This provides the fastest settling time response along with the lowest power and heat dissipation. A pair of external MOSFETs on the PWM amplifier provide output currents of up to 5A. Three low-bias current TIAs are built-in. These allow amplification for the laser back-facet photodiode and EDFA input and output photodiodes. For CW laser applications, the two unused TIAs can be used for etalon photodiode amplification, allowing continuous wavelength monitoring. The ADN8820 is available in a 7 x 7 mm lead-frame chip scale package (LFCSP) with a package height of less than 1 mm.
