ADF9010

DVDD, RxVDD , AVDD to GND1 .................−0.3 V to +3.9 V
RxVDD, AVDD to DVDD .............................−0.3 V to +0.3 V
VP to GND1...............................................−0.3 V to +5.5 V
Digital I/O Voltage to GND1..............−0.3 V to V_DD + 0.3 V
Analog I/O Voltage to GND1...........−0.3 V to AV_DD + 0.3 V
Charge Pump Voltage to GND1..........−0.3 V to VP to GND1
REFIN, LOEXTP, LOEXTN to GND1......−0.3 V to V_DD + 0.3 V
LOEXTP to LOEXTN...............................................±320 mV
Operating Temperature Range Industrial (B Version).......−40 to +85
Storage Temperature Range...................−65 to +150
Maximum Junction Temperature...............................150
LCSP JA Thermal Impedance................................26/W
Reflow Soldering Peak Temperature....................260/W
Time at Peak Temperature......................................40 sec
1 GND = AGND = DGND = 0 V.
Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
This device is a high-performance RF integrated circuit with an ESD rating of <0.5 kV and is ESD sensitive. Proper precautions should be taken for handling and assembly.

The ADF9010 is a fully integrated RF Tx modulator and Rx analog baseband front end that operates in the frequency range from 840 MHz to 960 MHz. The receive path consists of a fully differential I/Q baseband PGA, low-pass filter, and general signal conditioning before connecting to an Rx ADC for baseband conversion. The Rx LPF gain ranges from 3 dB to 24 dB, programmable in 3 dB steps. The Rx LPF features four programmable modes with cutoff frequencies of 330 kHz, 880 kHz, and 1.76 MHz, or the filter can be bypassed if necessary.

The transmit path consists of a fully integrated differential Tx direct I/Q upconverter with a high linearity PA driver amplifier. ADF9010 converts a baseband I/Q signal to an RF carrier-based signal between 840 MHz and 960 MHz. The highly linear transmit signal path ensures low output distortion.

Complete local oscillator (LO) signal generation is integrated on chip, including the integer-N synthesizer and VCO, which generate the required I and Q signals for transmit I/Q upconver-sion. The LO signal is also available at the output to drive an external RF demodulator. Control of all the on-chip registers is via a simple 3-wire serial interface. ADF9010 operates with a power supply ranging from 3.15 V to 3.45 V and can be powered down when not in use.
