ADCMP606BKSZ-RL, US $ 1.57-1.57, ADCMP606BKSZ-RL DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 003537774 Detail

ADCMP606BKSZ-RL: IC COMP TTL/CMOS 1CHAN SC70-6

ADCMP606BKSZ-RL Data Sheet

US $ 1.57~1.57 / Piece | Get Latest Price

Part Number:: ADCMP606BKSZ-RL
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~10000

Unit Price
$1.57

Processing time
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/12

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

ADCMP341 evaluate
Features: `400 mV ± 0.275% threshold`User programmable hysteresis via resistor string`Supply range...
ADCMP341YRJZ-REEL7 evaluate
US $.73 - 1.57 / Piece

IC COMPARATOR DUAL OD SOT23-8
ADCMP343 evaluate
Features: `400 mV ± 0.275% threshold`User programmable hysteresis via resistor string`Supply range...

Product Details

Quick Details

Series:	-	Package / Case :	SO-16
Manufacturer:	Analog Devices Inc	Type:	General Purpose
Number of Elements:	1	Output Type:	CML, Complementary, Rail-to-Rail
Voltage - Supply, Single/Dual (±):	2.5 V ~ 5.5 V	Voltage - Input Offset (Max):	5mV @ 2.5V
Current - Input Bias (Max):	5µA @ 2.5V	Current - Output (Typ):	50mA
Current - Quiescent (Max):	26mA	CMRR, PSRR (Typ):	50dB CMRR, 50dB PSRR
Propagation Delay (Max):	2.1ns	Hysteresis:	100µV
Operating Temperature:	-40°C ~ 125°C	Package / Case:	6-TSSOP, SC-88, SOT-363
Mounting Type:	Surface Mount

Description

Series: -
Type: General Purpose
Number of Elements: 1
Mounting Type: Surface Mount
Packaging: Tape & Reel (TR)Alternate Packaging
Operating Temperature: -40°C ~ 125°C
Current - Output (Typ): 50mA
Package / Case: 6-TSSOP, SC-88, SOT-363
Manufacturer: Analog Devices Inc
Voltage - Supply, Single/Dual (±): 2.5 V ~ 5.5 V
Voltage - Input Offset (Max): 5mV @ 2.5V
Current - Input Bias (Max): 5µA @ 2.5V
CMRR, PSRR (Typ): 50dB CMRR, 50dB PSRR
Hysteresis: 100µV
Current - Quiescent (Max): 26mA
Output Type: CML, Complementary, Rail-to-Rail
Propagation Delay (Max): 2.1ns

Parameters:

Technical/Catalog Information	ADCMP606BKSZ-RL
Vendor	Analog Devices Inc
Category	Integrated Circuits (ICs)
Type	General Purpose
Output Type	CML, Complementary, Rail-to-Rail
Voltage - Supply	2.5 V ~ 5.5 V
Number of Elements	1 - Single
Package / Case	SC-70-6, SC-88, SOT-323-6, SOT-363
Packaging	Tape & Reel (TR)
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	ADCMP606BKSZ RL ADCMP606BKSZRL
