Features: · 14-bit resolution· 3MPPS throughput rate (14-bits)· Functionally complete· Very low noise· Excellent Signal-to-Noise ratio· Edge triggered· Small, 40-pin, TDIP package· Low power, 500mW typical· Low cost· Programmable Analog BandwidthSpecifications PARAMETERS MIN. TYP. MA...
ADCDS-1403: Features: · 14-bit resolution· 3MPPS throughput rate (14-bits)· Functionally complete· Very low noise· Excellent Signal-to-Noise ratio· Edge triggered· Small, 40-pin, TDIP package· Low power, 500mW ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Features: • 14-bit resolution• 5MPPS throughput rate (14-bits)• Functionally com...
PARAMETERS |
MIN. |
TYP. |
MAX. |
UNITS |
+12V Supply (Pin 32) |
0 |
- |
+14 |
Volts |
5V Supply (Pin 31) |
0.3 |
- |
+6.5 |
Volts |
+5V Supply (Pin 28, 29) |
0 |
- |
6.5 |
Volts |
Digital Input (Pin 23, 24) |
0.3 |
- |
Vdd+0.3V |
Volts |
Analog Input (Pin 3,4,5) |
-5 |
- |
+5 |
Volts |
Lead Temperature (10 seconds) |
- |
- |
300 |
°C |
The ADCDS-1403 is an application-specific video signal processor designed for electronic-imaging applications that employ CCD's (charge coupled devices) as their photodetector. The ADCDS-1403 incorporates a "user configurable" input amplifier, a CDS (correlated double sampler) and a sampling A/D converter in a single package, providing the user with a complete, high performance, lowcost, low-power, integrated solution.
The key to the ADCDS-1403's performance is a unique, highspeed, high-accuracy CDS circuit, which eliminates the effects of residual charge, charge injection and "kT/C" noise on the CCD's output floating capacitor, producing a "valid video" output signal. The ADCDS-1403 digitizes this resultant "valid video" signal using a high-speed, low-noise sampling A/D converter.
The ADCDS-1403 requires only the rising edge of start convert pulse to initiate its conversion process. Additional features of the ADCDS-1403 include gain adjust, offset adjust, precision +2.4V reference, and a programmable analog bandwidth function.
