ADC804SH

DescriptionThe ADC804SH is a 12-bit successive approximation analog-to-digital,custom-designed for freedom from latch-up and for optimum AC performance.It is complete with a comparator,a monolithic 12-bit DAC which includes a 6.3V reference laser-trimmed for minimum temperature coefficient,and a C...

product image

ADC804SH Picture
SeekIC No. : 004274230 Detail

ADC804SH: DescriptionThe ADC804SH is a 12-bit successive approximation analog-to-digital,custom-designed for freedom from latch-up and for optimum AC performance.It is complete with a comparator,a monolithic ...

floor Price/Ceiling Price

Part Number:
ADC804SH
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/4

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Description

The ADC804SH is a 12-bit successive approximation analog-to-digital,custom-designed for freedom from latch-up and for optimum AC performance.It is complete with a comparator,a monolithic 12-bit DAC which includes a 6.3V reference laser-trimmed for minimum temperature coefficient,and a CMOS logic chip containing the successive approximation register (SAR),clock,and all other associated logic functions.

Inter scaling resistors ADC804SH are provided for the selection of ±2.5V,±5V,±10V,0 to +5V,or 0 to
+10V.Gain and offset errors may be externally trimmed to zero,enabling initial end-point accuracies of better than ±0.012% (±1/2LSB).The ADC804SH has two grades,one completely specified for -25 to +85 operation (ADC804BH),and the other for -55 to +125 operation.

The maximum conversion time of 17sec makes the ADC804SH ideal for a wide range 12-bit applications requiring system throughput sampling rates up to 59kHz.In addition,an external clock may be used to synchronize the converter to the systerm clock or to obtain faster operation.As an added benifit for ADC80 users employing the serial output capability,the ADC804SH is designed to replace or provide an alternate source to ADC80 with a mimimum of circuit board changes and it provides a 40% reduction in conversion time.
