ADC1251CIJ

IC ADC 12BIT W/S&H +SIGN 24CDIP

product image

ADC1251CIJ Picture
SeekIC No. : 003484599 Detail

ADC1251CIJ: IC ADC 12BIT W/S&H +SIGN 24CDIP

floor Price/Ceiling Price

Part Number:
ADC1251CIJ
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: - Manufacturer: National Semiconductor
Number of Bits: 12 Sampling Rate (Per Second): 83k
Data Interface: DSP Number of Converters: 2
Power Dissipation (Max): 113mW Voltage Supply Source: Analog and Digital, Dual ±
Operating Temperature: -40°C ~ 85°C Maximum Operating Temperature : + 125 C
Mounting Type: Through Hole Package / Case: 24-CDIP (0.600", 15.24mm)
Supplier Device Package: 24-CDIP Packaging: Tube

Description

Series: -
Number of Converters: 2
Operating Temperature: -40°C ~ 85°C
Number of Bits: 12
Packaging: Tube
Mounting Type: Through Hole
Voltage Supply Source: Analog and Digital, Dual ±
Number of Inputs and Type: 1 Single-Ended, Unipolar; 1 Single-Ended, Bipolar
Manufacturer: National Semiconductor
Supplier Device Package: 24-CDIP
Sampling Rate (Per Second): 83k
Power Dissipation (Max): 113mW
Data Interface: DSP
Package / Case: 24-CDIP (0.600", 15.24mm)


Pinout

  Connection Diagram


Description

The ADC1251CIJ is a CMOS 12-bit plus sign successive approximation analog-to-digital converter. On request,the ADC1251CIJ goes through a self-calibration cycle that adjusts for any zero, full scale, or linearity errors. The ADC1251CIJ also has the ability to go through an Auto-Zero cycle that corrects the zero error during every conversion.

The analog input to the ADC1251CIJ is tracked and held by the internal circuitry, so an external sample-and-hold is not required.The ADC1251CIJ has an S/H control input which directly controls the track-and-hold state of the A/D. A unipolar analog input voltage range (0 to a5V) or a bipolar range (b5V to a5V) can be accommodated with g5V supplies.The 13-bit data result is available on the eight outputs of the ADC1251CIJ in two bytes, high-byte first and sign extended.The digital inputs and outputs are compatible with TTL or CMOS logic levels.The ADC1251CIJ has six features.The first one is self-calibration provides excellent temperature stability.The second one is internal sample-and-hold.The third one is 8-bit P/DSP interface.The fourth one is bipolar input range with a single a5V reference.The fifth one is no missing codes over temperature.The sixth one is TTL/MOS input/output compatible.

Life support devices or systems are devices or systems which, (a) are intended for surgical implan into the body, or (b) support or sustain life, and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in a significant injury to the user.A critical component is any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness.




Parameters:

Technical/Catalog InformationADC1251CIJ
VendorNational Semiconductor
CategoryIntegrated Circuits (ICs)
Number of Bits12
Package / Case24-CDIP (600 mil)
Data InterfaceParallel
PackagingTube
Sampling Rate (Per Second)83k
Operating Temperature-40°C ~ 85°C
Voltage Supply SourceAnalog and Digital, Dual ±
Number of Inputs and Type1 Single-Ended, Unipolar; 1 Single-Ended, Bipolar
Number of Converters2
Power Dissipation (Max)113mW
Lead Free StatusContains Lead
RoHS StatusRoHS Non-Compliant
Other Names ADC1251CIJ
ADC1251CIJ
