ADC11L066

Single supply operation
 Low power consumption
 Power down mode
 On-chip reference buffer

VA, VD, VDR                                                  4.2V
|VAVD|                                                      100 mV
Voltage on Any Pin                                      −0.3V to VA or VD
+0.3V
Input Current at Any Pin (Note 3)                ±25 mA
Package Input Current (Note 3)                  ±50 mA
Package Dissipation at TA = 25°C              See (Note 4)
ESD Susceptibility
Human Body Model (Note 5)                        2500V
Machine Model (Note 5)                               250V
Soldering Temperature,
Infrared, 10 sec. (Note 6)                            235°C
Storage Temperature                                  −65°C to +150°C

The ADC11L066 is a monolithic CMOS analog-to-digital converter capable of converting analog input signals into 11-bit digital words at 66 Megasamples per second (MSPS), minimum, with typical operation possible up to 80 MSPS. This converter uses a differential, pipeline architecture with digital error correction and an on-chip sample-and-hold circuit to minimize die size and power consumption while providing excellent dynamic performance. A unique sample-and-hold stage yields a full-power bandwidth of 450 MHz. Operating on a single 3.3V power supply, this device consumes just 357 mW at 66 MSPS, including the reference current. The Power Down feature reduces power consumption to just 50 mW.

The differential inputs of ADC11L066 provide a full scale input swing equal to ±VREF with the possibility of a single ended input. Full use of the differential input is recommended for optimum performance. For ease of use, the buffered, high impedance, single-ended reference input is converted on-chip to a differential
reference for use by the processing circuitry. Output data format is 11-bit offset binary.

This device ADC11L066 is available in the 32-lead LQFP package and will operate over the industrial temperature range of −40°C to +85°C.
