ADC1005CCJ-1

Series: -
Number of Bits: 10
Number of Converters: 1
Power Dissipation (Max): -
Voltage Supply Source: Single Supply
Sampling Rate (Per Second): -
Packaging: Tube
Mounting Type: Through Hole
Operating Temperature: 0°C ~ 70°C
Data Interface: Parallel
Number of Inputs and Type: 1 Differential, Unipolar
Manufacturer: National Semiconductor
Package / Case: 20-CDIP (0.300", 7.62mm)
Supplier Device Package: 20-CDIP


Pinout




Description

The ADC1005CCJ-1 is a CMOS 10-bit successive approximation A/D converter. The 20-pin ADC1005CCJ-1 outputs 10-bit data in a two-byte format for interface with 8-bit microprocessors.The ADC1005CCJ-1 has differential inputs to permit rejection of common-mode signals, allow the analog input range to be offset, and also to permit the conversion of signals not referred to ground. In addition, the reference voltage can be adjusted, allowing smaller voltage spans to be measured with 10-bit resolution.

The ADC1005CCJ-1 has seven features.The first one is easy interface to all microprocessors.The second one is differential analog voltage inputs.The third one is operates ratiometrically or with 5 VDC voltage reference or analog span adjusted voltage reference.The fourth one is 0V to 5V analog input voltage range with single 5V supply.The fifth one is on-chip clock generator.The sixth one is TLL/MOS input/output compatible.The seventh one is 0.3" standard width 20-pin DIP.

Life support devices ADC1005CCJ-1 or systems are devices or systems which, (a) are intended for surgical implan into the body, or (b) support or sustain life, and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in a significant injury to the user.A critical component is any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness.
