Series: -
Manufacturer: Analog Devices Inc
Mounting Type: Through Hole
Current - Supply: 1.2mA
Voltage - Supply: 5.0V ~ 36V, ±3.0V ~ 18V
Package / Case: TO-100-10 Metal Can
Supplier Device Package: TO-100-10
Packaging: Bulk
DescriptionThe AD536ASH is designed as one kind of integrated circuit true RMS-to-DC converter which performs true rms-to-dc conversion.Also it computes the true rms value of any complex input waveform containing ac and dc components.It has a crest factor compensation scheme which allows measurements with 1% error at crest factors up to 7.With the help of externally supplied reference current, the 0 dB level can be conveniently set by the user to correspond to any input level from 0.1 to 2 volts rms.
Features of the AD536ASH are:(1)true RMS-to-DC conversion;(2)laser-trimmed to high accuracy;(3)wide response capability:computes RMS of AC and DC signals,450 kHz bandwidth: V rms>100 mV,2 MHz bandwidth:V rms>1 V,signal crest factor of 7 for 1% error;(4)dB output with 60 dB range;(5)low power:1.2 mA quiescent current;(6)single or dual supply operation;(7)monolithic integrated circuit;(8)-55 to +125 operation (AD536AS).
The absolute maximum ratings of the AD536ASH can be summarized as:(1)supply voltage (dual supply):±18 V;(2)supply voltage (single supply):+36 V;(3)internal power dissipation:500 mW;(4)maximum input voltage:±25 V peak;(5)buffer maximum input voltage:±VS;(6)maximum input voltage:±25 V peak;(7)storage temperature range:-55°C to +150°C;(8)operating temperature range:-55°C to +125°C;(9)lead temperature range(soldering 60 sec):+300°C;(10)ESD rating:1000 V.If you want to know more information such as the electrical characteristics about the AD536ASH,please download the datasheet in www.seekic.com or www.chinaicmart.com.
Parameters: | Technical/Catalog Information | AD536ASH |
| Vendor | Analog Devices Inc |
| Category | Integrated Circuits (ICs) |
| Mounting Type | Through Hole |
| Package / Case | TO-100-10, Metal Can |
| Voltage - Supply | 5.0V ~ 36V, ±3.0V ~ 18V |
| Current - Supply | 1.2mA |
| Packaging | Bulk |
| Drawing Number | * |
| RoHS Status | RoHS Non-Compliant |
| Other Names | AD536ASH
