ACD0900

Features: • Integrated Monolithic Downconverter• 8 dB Noise Figure• 10 dB Conversion Gain• High Linearity• Small Size• Low Cost• High ReliabilitySpecifications RF Frequency (MHz) 900-1200 IF Frequency (MHz) 35-150 Phase Noise at 10 KHz Off...

product image

ACD0900 Picture
See larger image
SeekIC No. : 004266989 Detail

ACD0900: Features: • Integrated Monolithic Downconverter• 8 dB Noise Figure• 10 dB Conversion Gain• High Linearity• Small Size• Low Cost• High ReliabilitySpecificati...

ACD0900 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ACD0900
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Integrated Monolithic Downconverter
• 8 dB Noise Figure
• 10 dB Conversion Gain
• High Linearity
• Small Size
• Low Cost
• High Reliability




Specifications

RF Frequency (MHz) 900-1200
IF Frequency (MHz) 35-150
Phase Noise at 10 KHz Offset (dBc/Hz) Typ -89
Phase Noise at 10 KHz Offset (dBc/Hz) Max -85.5
Conversion Gain (dB) Typ 9.5
Noise Figure (dB) Typ 8.0
Power Consumption (mW) Typ 400


PARAMETER MIN MAX UNIT
VDDIF, VDDLO, VOSC - 9 Volts
VRF, VTCKT(1) - 0 Volts
Storage Temperature -55 200 °C
Soldering Temperature - 260 °C
Soldering Time - 5 Sec.
RF Input Power - +10 dBm
LO Input Power - +17 dBm
Thermal Resistance - 25 °C/W

Note:
(1) VTCKT : Maximum voltage that may be applied to pin 11 of the device
without damaging the IC. DC blocking capacitor (1500 pF) between
pin 11 and the external tuning circuit is mandatory.




Description

The ACD0900 MMIC is a high performance downconverter fabricated entirely in GaAs. It is designed for use as the second conversion stage in double-conversion tuners and cable modems, downconverting 900 -1200 MHz RF inputs to a fixed IF of 35 - 150 MHz (depending on LO frequency).

The IC ACD0900 incorporates a low noise amplifier, high linearity double balanced mixer, phase splitter and oscillator in a modified SOIC 16 lead surface mount package. The high degree of functionality allows tuner manufactures to reduce size and cost by lowering the component count and decreasing the amount of production alignment steps, while significantly improving performance and reliability.
