AC03FGM

Features: Gate trigger current (mode I, III, and IV) at 12 mA or less is guaranteed. This transistor features a small and lightweight package and is easy to handle even on the mounting surface due to its TO- 202AA dimensions. Processing of lead wires and heatsink (tablet) using jigs is also possib...

product image

AC03FGM Picture
See larger image
SeekIC No. : 004264378 Detail

AC03FGM: Features: Gate trigger current (mode I, III, and IV) at 12 mA or less is guaranteed. This transistor features a small and lightweight package and is easy to handle even on the mounting surface due t...

AC03FGM Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
AC03FGM
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Gate trigger current (mode I, III, and IV) at 12 mA or less is guaranteed.
This transistor features a small and lightweight package and is easy to
handle even on the mounting surface due to its TO- 202AA dimensions.
Processing of lead wires and heatsink (tablet) using jigs is also possible.
High degrees-of-freedom applications design is available due to
high gate trigger sensitivity and small hold current distribution.
Employs flame-retardant epoxy resin (UL94V-0).




Application

Noncontact  switches of motor speed control, heater
temperature control, lamp light control


Specifications

PARAMETER SYMBOL
 AC03DGM AC03FGM Unit Remarks

Non-repetitive peak off-state voltage

 V
DSM		 500 700 V

-

Repetitive peak off-voltage

 VDRM 400 600 V Refer to Figures
11 and 12.
Effective on-state current
 IT(RMS) 3 (TC = 92°C)
 A Refer to Figure 2.
Surge on-state current ITSM 30 (50 Hz 1 cycle)
33 (60 Hz 1 cycle)		 A -
Fusing current FiT2 dt
 4.0 (1 ms t 10 ms) A2S -
Critical rate of rise of on-state
current		 dI /dt
T		 40 A/ s
 -
Peak gate power dissipation PGM 3 (f 50 Hz, Duty 10 %) W -
Average gate power dissipation PG(AV) 0.3 W -
Peak gate current IGM ±0.5 (f 50 Hz, Duty 10 %) A -
Junction temperature Tj -40 to +125 °C -
Storage temperature Tstg -55 to +150 °C -



Description

The AC03EGM and AC03FGM are fully diffused mold TRIACs with an effective on-current of 3 A. The repeat peak off-voltages are 400 V and 600 V.
