Features: 20 AQuiescent CurrenLow Dropout: 200 mV (typical)Guaranteed 150 mAOutputHigh accuracy: ±2Current limit protectionOver-Temperature protectionExtremely Low power shutdown modeLow Temperature CoefficientFactory programmed output voltages--1.8V to 3.5VStable operation with virtually any outp...
AAT3201: Features: 20 AQuiescent CurrenLow Dropout: 200 mV (typical)Guaranteed 150 mAOutputHigh accuracy: ±2Current limit protectionOver-Temperature protectionExtremely Low power shutdown modeLow Temperature...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
US $.22 - .28 / Piece
Battery Management 500mA USB Port/Adptr Li-Ion/Ply Batt Chgr
Symbol | Description |
Value | Units |
VIN |
Input Voltage | -0.3 to 6 | V |
VEN |
EN to GND Voltage | -0.3 to 6 | V |
VENIN(MAX) | Maximum EN to Input Voltage | 0.3 | V |
IOUT | I Maximum DC Output Current | PD /(VIN -VO ) | mA |
TJ |
Operating Junction Temperature Range | -40 to 150 | °C |
TLEAD | Maximum Soldering Temperature (at leads, 10 sec) | 300 | °C |
The AAT3201 PowerLinear™ OmniPower Low Dropout Linear Regulator is ideal for systems where a low cost solution is critical. This device features extremely low quiescent current which is typically 20A. Dropout voltage is also very low typically 200mV. The AAT3201 has an Enable pin feature, which when pulled low will enter the LDO regulator into a shutdown mode removing power from its load and offering extended power conser- vation capabilities for portable battery powered applications.
The AAT3201 PowerLinear OmniPower Low Dropout Linear Regulator is ideal for systems where a low-cost solution is critical. This device features extremely low quiescent current which is typically 20A. Dropout voltage is also very low, typically 200mV. The AAT3201 has an Enable pin feature which, when pulled low, will enter the LDO regulator into a shutdown mode removing power from its load and offering extended power conservation capabilities for portable battery-powered applications. The AAT3201 has output short circuit and over-current protection. In addition, the device has an over-temperature protection circuit that will shutdown the LDO regulator during extended over-current events. Since only a small, 1F ceramic output capacitor is recommended, the AAT3201 is a truly cost-effective voltage conversion solution. The AAT3201 is available in the space-saving 5-pin SOT23 package. The device is rated over the -40C to +85C temperature range.
