Specifications On-chip charge pump for 7 V minimum input supply voltage High-current gate drive for driving a wide range of N-channel MOSFETs Bootstrapped gate drive with charge pump for 100% duty cycle Overtemperature protection Und...
A3946: Specifications On-chip charge pump for 7 V minimum input supply voltage High-current gate drive for driving a wide range of N-channel MOSFETs Bootstrapped ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Description
The A3946 is designed specifically for applications that require high power unidirectional DC motors, three-phase brushless DC motors, or other inductive loads. The A3946 provides two high-current gate drive outputs that are capable of driving a wide range of power N-channel MOSFETs. The high-side gate driver switches an N-channel MOSFET that controls current to the load, while the low-side gate driver switches an N-channel MOSFET as a synchronous rectifier.
A bootstrap capacitor provides the above-battery supply voltage required for N-channel MOSFETs. An internal top-off charge pump for the high side allows DC (100% duty cycle) operation of the half-bridge.
The A3946 is available in a choice of two power pack ages: a 16-lead SOIC with two internally-fused pins for enhanced power dissipation (part number suffix LB), and a 16-lead TSSOP with exposed thermal pad (suffix LP). Both packages have a lead (Pb) free version, with 100% matte tin plated leadframes (suffix -T).
