A3163ELT

Features: `Internal Current Regulator for 2-Wire Operation`Output Slew Rate Controlled`3.5 V to 24 V Operation . Needs Only An Unregulated Supply`Reverse Battery Protection`Excellent Temperature Stability`Activate with Small, Commercially Available Permanent Magnets`Small Size`Solid-State Reliabil...

product image

A3163ELT Picture
See larger image
SeekIC No. : 004260162 Detail

A3163ELT: Features: `Internal Current Regulator for 2-Wire Operation`Output Slew Rate Controlled`3.5 V to 24 V Operation . Needs Only An Unregulated Supply`Reverse Battery Protection`Excellent Temperature Sta...

A3163ELT Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
A3163ELT
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

`Internal Current Regulator for 2-Wire Operation
`Output Slew Rate Controlled
`3.5 V to 24 V Operation . Needs Only An Unregulated Supply
`Reverse Battery Protection
`Excellent Temperature Stability
`Activate with Small, Commercially Available Permanent Magnets
`Small Size
`Solid-State Reliability . No Moving Parts
`Resistant to Physical Stress


Specifications

Supply Voltage, VCC ....................... 26.5 V
Reverse Battery Voltage, VRCC ........ -16 V
Magnetic Flux Density, B............. Unlimited
Package Power Dissipation, PD See Graph
Junction Temperature, TJ ........... +170°C
Operating Temperature Range,
TA ................................. -40°C to +85°C
Storage Temperature Range,
TS .............................. -65°C to +170°C


Description

This Hall-effect switch A3163ELT is a monolithic integrated circuit designed to operate continuously over extended temperatures to +85°C. The unipolar switching characteristic makes this device ideal for use with a simple bar or rod magnet. The A3163ELT and A3163EUA are identical except for package.

Each device A3163ELT includes a voltage regulator for operation with supply voltages of 3.5 to 24 volts, reverse-battery protection, quadratic Hallvoltage generator for low offset, temperature compensation circuitry, small-signal amplifier, Schmitt trigger, and a constant-current opencollector output, wired internally for true 2-wire operation. Noise radiation is limited by control of the output-current slew rate.

Two package styles of A3163ELT provide a magnetically optimized package for most applications. Suffix 'LT' is a miniature SOT89/TO-243AA transistor package for surface-mount applications; suffix 'UA' is a three-lead ultra-mini SIP for through-hole mounting; it is also available with lead forming for surface-mount applications (suffix 'UA-TL').
