The A3058EU/LU series hall effect gear-tooth sensors are monolithic integrated circuits that switch in response to differential magnetic fields created by ferrous targets.The A3058EU belongs to A3058EU/LU series.
Features of the A3058EU are:(1)senses ferrous targets down to zero RPM;(2)large effective air gap;(3)wide operating temperature range;(4)operation from unregulated supply;(5)high-speed operation;(6)output compatible with all logic families;(7)reverse battery protection;(8)solid-state reliability;(9)resistant to physical stress.
The absolute maximum ratings of the A3058EU can be summarized as:(1):the parameter is supply voltage,the symbol is VCC,the rating is 28,the unit is V;(2):the parameter is reverse battery voltage,the symbol is VRCC,the rating is -30,the unit is V;(3):the parameter is magnetic flux desity,the symbol is B,the rating is unlimited;(4):the parameter is output OFF voltage,the symbol is VOUT,the rating is 28,the unit is V;(5):the parameter is reverse output voltage,the symbol is VOUT,the rating is -0.5,the unit is V;(6):the parameter is output current,the symbol is IOUT,the rating is 25,the unit is mA;(7):the parameter is package power dissipation,the symbol is PD,the rating is 500,the unit is mW;(8):the parameter is operating temperature range,the symbol is TA,the rating is -40 to +85,the unit is ;(9):the parameter is storage temperature range,the symbol is TS,the rating is -65 to +170,the unit is .
