A085FW01

DescriptionThe A085FW01 is designed as one kind of 17 dBm power amplifier. A085FW01 has three points of features (1)P-1 dB: 17 dBm; (2)NF : 3.0 dB; (3)Small Signal Gain: 32 dB. This device provides high gain and low noise figure and requires only a +15V DC power supply. Also the high efficiency op...

product image

A085FW01 Picture
SeekIC No. : 004259700 Detail

A085FW01: DescriptionThe A085FW01 is designed as one kind of 17 dBm power amplifier. A085FW01 has three points of features (1)P-1 dB: 17 dBm; (2)NF : 3.0 dB; (3)Small Signal Gain: 32 dB. This device provides ...

floor Price/Ceiling Price

Part Number:
A085FW01
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Description

The A085FW01 is designed as one kind of 17 dBm power amplifier. A085FW01 has three points of features (1)P-1 dB: 17 dBm; (2)NF : 3.0 dB; (3)Small Signal Gain: 32 dB. This device provides high gain and low noise figure and requires only a +15V DC power supply. Also the high efficiency operation is achieved by using hybrid MIC designs and advanced GaAs PHEMT devices.

The electrical characteristics of A085FW01 can be summarized as:(1)Frequency Range: 8.5 to 10.5 GHz;(2)Small Signal Gain Flatness: +/- 1.0 dB;(3)Small Signal Gain: 31 to 34 dB;(4)Noise Figure: 3.0 dB;(5)1 dB Compression Power: 17 dBm;(6)Input Power Handling: 20 dBm;(7)Input VSWR: 1.9:1;(8)Output VSWR: 1.9:1;(9)DC Supply Voltage (with built-in regulator): 15 Volt;(10)Current Supply: 275 mA. If you want to know more information about the A085FW01, please download the datasheet in www.seekic.com or www.chinaicmart.com .
