953201BFLF

Specifications

Temperature C Voltage 3.3 V Package SSOP 56 Speed NA


Description

PC MAIN CLOCK
The ICS953201 is part of a whole new line of ICS clock generators and buffers called TCH? (Timing Control Hub). Thispart incorporates ICS's newest clock technology which offers more robust features and functionality. Employing theuse of a serially programmable I2C interface, ICS953201 can adjust the output clocks by configuring the frequencysetting, the output divider ratios, selecting the ideal spread percentage, the output skew, the output strength, andenabling/disabling each individual output clock. M/N control can configure output frequency with resolution up to0.1MHz increment.

ICS953201 Output Features:

2 - Differential pair push-pull CPU clocks @3.3V

6 - PCI-Ex differential pairs

6 - PCICLK @ 3.3V

3 - AGPCLK @ 3.3V

1 - 48MHz @ 3.3V fixed.

1 - 24/48MHz @ 3.3V

2 - REF @ 3.3V, 14.318MHz.
