947C491K801CBMS

Film Capacitors 490uF 800V 55C

product image

947C491K801CBMS Picture
See larger image
SeekIC No. : 00954767 Detail

947C491K801CBMS: Film Capacitors 490uF 800V 55C

947C491K801CBMS Data Sheet

floor Price/Ceiling Price

US $ 60.22~80.27 / Piece | Get Latest Price
Part Number:
947C491K801CBMS
Mfg:
Cornell Dubilier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~10
  • 10~25
  • 25~50
  • Unit Price
  • $80.27
  • $68.17
  • $66.99
  • $60.22
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product Type : DC Link Dielectric : Polypropylene (PP)
Capacitance : 490 uF Tolerance : 10 %
Voltage Rating : 800 Volts Series : 947C
Operating Temperature Range : - 40 C to + 85 C Termination Style : Screw
Lead Spacing : 45 mm Dimensions : 92 mm Dia. x 120 mm L

Description

Dielectric : Polypropylene (PP)
Tolerance : 10 %
Termination Style : Screw
Product Type : DC Link
Voltage Rating : 800 Volts
Operating Temperature Range : - 40 C to + 85 C
Series : 947C
Lead Spacing : 45 mm
Capacitance : 490 uF
Dimensions : 92 mm Dia. x 120 mm L


Parameters:

Technical/Catalog Information947C491K801CBMS
VendorCornell Dubilier Electronics (CDE)
CategoryCapacitors
Capacitance490F
Voltage - Rated 800V
Tolerance±10%
Dielectric MaterialMetallized Polypropylene Film
Package / CaseScrew Mount
PackagingBulk
Maximum Temperature-40°C ~ 85°C
Lead Spacing1.772" (45.00mm)
ESR (Equivalent Series Resistance)1.6 mOhm
Lifetime @ Temp.5000 Hrs @ 85°C
Mounting TypeChassis Mount
FeaturesHigh Current and High Frequency Applications
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names 947C491K801CBMS
947C491K801CBMS
338 1401 ND
3381401ND
338-1401
