9334

Plating :
Type : Screw
Thread Size : 6-32
Material : Nylon
Screw Head : Slotted, Pan Head
Screw Type : Machine, Nylon
Length : 0.25 in


Features:

 Common clear
 Easily expandable
 Random (addressable) data entry
 Serial to parallel capability
 8 bits of storage/output of each bit available
 Active high demultiplexing/decoding capability
 Alternate Military/Aerospace device (9334) is available. Contact a National Semiconductor Sales Office/Distributor for specifications.


Specifications

If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/Distributors for availability and specifications.

Supply Voltage                                                     7V
Input Voltage                                                    5.5V
Operating Free Air Temperature Range
Military                                           -55 to +125
Commercial                                           0 to +70
Storage Temperature Range         -65 to +150

Note: The ``Absolute Maximum Ratings'' are those values beyond which the safety of the device cannot be guaranteed.
The device should not be operated at these limits. The parametric values defined in the ``Electrical Characteristics'' table are not guaranteed at the absolute maximum ratings. The ``Recommended Operating Conditions'' table will define the conditions for actual device operation.


Description

The DM9334 is a high speed 8-bit Addressable Latch designed for general purpose storage applications in digitalsystems. It is a multifunctional device capable of storing single line data in eight addressable latches, and being a oneof- eight decoder and demultiplexer with active level high outputs. The DM9334 also incorporates an active level low common clear for resetting all latches, as well as an active level low enable.

The DM9334 has four modes of operation which are shown in the mode selection table. In the addressable latch mode, data on the data line (D) is written into the addressed latch. The addressed latch will follow the data input with all nonaddressed latches remaining in their previous states. In the memory mode, all latches remain in their previous state and are unaffected by the data or address inputs.

In the one-of-eight decoding or demultiplexing mode, the addressed output will follow the state of the D input with all other inputs in the low state. In the clear mode all outputs are low and unaffected by the address and data inputs.

When operating the DM9334 as an addressable latch, changing more than one bit of the address could impose a transient wrong address. Therefore, this should only be done while in the memory mode.

The function tables summarize the operation of the DM9334.
