Product Details

Description



Features:

· Very Low Peripheral Component Count
· No Critical System Resistors
· Wide Supply Voltage Operating Range (4.0V ~ 24V)
· Overvoltage Shutdown (30V)
· Dwell Automatically Adjusts to Produce Optimum Stored Energy without Waste
· Externally Adjustable Peak Current
· Transient Protected Inputs and Outputs


Pinout

Connection Diagram


Specifications

PARAMETER SYMBOL RATING UNIT
Power Supply Voltage-Steady State Transient 300ms or less VCC 24 V
90
Output Sink Current-Steady State Transient 300ms of less IOUT(SINK) 300 mA
1.0 A
Power Dissipation
Derate above 25		 PD 1.05 W
12 mW/
Junction Temperature TJ +125
Operating Temperature TOPR -20~+85
Storage Temperature TSTG -40 ~ 150

Note 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
            Absolute maximum ratings are stress ratings only and functional device operation is not implied.
        2. The device is guaranteed to meet performance specification within 0~+70 operating temperature range
and assured by design from -20~+85.


Description

This 93334 is designed to use the signal from a reluctor type ignition pickup to produce a well controlled output from a power darlington output transistor.
