908E621

The 908E621 is an integrated single-package solution that  includes a high-performance HC08 microcontroller with a  SMARTMOS^TM analog control IC. The HC08 includes flash memory,  a timer, enhanced serial communications interface (ESCI), an  analog-to-digital converter (ADC), serial peripheral interface (SPI)  (only internal), and an internal clock generator module. The analog  control die of 908E621 provides four half-bridge and three high-side outputs with  diagnostic functions, a Hall-Effect sensor input, analog inputs,  voltage regulator, window watchdog, and local interconnect network  (LIN) physical layer.

The single-package solution, together with LIN, provides optimal  application performance adjustments and space-saving PCB design.  908E621 is well suited for the control of automotive high-end mirrors.
