82B715

Features:

Dual, bi-directional, unity voltage gain buffer
I² C bus compatible
Logic signal levels may include both supply and ground
X10 impedance transformation
Wide supply voltage range



Pinout




Specifications

SYMBOL	PARAMETER	LIMITS		UNIT
		MIN.	MAX.
VCC to GND	Supply voltage range VCC	0.3	+12	V
Vbus	Voltage range I2 C Bus, SCL or SDA	0	VCC	V
Vbuff	Voltage range Buffered Bus	0	VCC	V
I	DC current (any pin)		60	mA
Ptot	Power dissipation		300	mW
Tstg	Storage temperature range	-55	+125
Tamb	Operating ambient temperature range	-40	+85

Description

The 82B715 is a bipolar integrated circuit intended for application in I² C bus systems.

While retaining all the operating modes and features of the I² C system it permits extension of the practical separation distance between components on the I² C bus by buffering both the data (SDA) and the clock (SCL) lines.

The I² C bus capacitance limit of 400pF restricts practical communication distances to a few meters. Using one 82B715 at each end of longer cables reduces the cable loading capacitance on the I² C bus by a factor of 10 times and may allow the use of low cost general purpose wiring to extend bus lengths.
