8001204JA

The 8001204JA is designed as one kind of DIP reed relay device that can be used in the needs of automated test equipment, instrumentation, data acquisition, and process control requirements applications.

Features of the 8001204JA are:(1)High reliability, hermetically sealed contacts for long life. Proven to 500 million operations; (2)Contact forms; 1A, 2A, 1B and 1C available; (3)Surface mount version available; (4)Molded thermoset body on integral lead frame design; (5)Optional Electrostatic Shield for reducing capacitive coupling offered on some models; (6)Coil suppression diode available upon request; (7)High Voltage Breakdown versions available; (8)14 - Pin DIP Industry standard package.

The environmental ratings of the 8001204JA can be summarized as:(1)Storage Temp: -35°C to +100°C;; (2)Operating Temp: -20°C to +85°C; (3)The operate and release voltage and the coil resistance are specified at 25°C.; (4)These values vary by approximately 0.4%/°C as the ambient temperature varies.; (5)Vibration: 20 G's to 2000 Hz; Shock: 50 G's. If you want to know more information about 8001204JA, please download the datasheet in www.seekic.com or www.chinaicmart.com .
