7MBI40N-120

The 7MBI40N-120 is designed as one kind of IGBT module device that has some points of features:(1)including brake chopper; (2)square RBSOA; (3)low saturation voltage; (4)overcurrent limiting function (4 to 5 times rated current).

The absolute maximum ratings of the 7MBI40N-120 (inverter) can be summarized as:(1)Collector-Emitter Voltage: 1200 V;(2)Gate -Emitter Voltage: +/- 20 V;(3)Collector Current Ic: 40 A;(4)Collector Current Ic PULSE: 80 A;(5)Collector Power Dissipation: 320 W;(6)Operating Junction Temperature: +150 °C;(7)Storage Temperature: -40 °C to +125 °C ;(8)Isolation Voltage: 2500 V;(9)Mounting Screw Torque: 3.5 N.m;(10)Mounting Screw Torque: 3.5 N.m.

The electrical characteristics of 7MBI40N-120 (inverter) can be summarized as:(1)Zero Gate Voltage Collector Current: 3.0 mA;(2)Gate-Emitter Leackage Current: 15 A;(3)Gate-Emitter Threshold Voltage: 4.5 to 7.5 V;(4)Collector-Emitter Saturation Voltage: 3.3 V;(5)Input capacitance: 6200 (typ.) pF;(6)Diode Forward On-Voltage: 3.0 V;(7)Reverse Recovery Time: 350 ns. If you want to know more information about the 7MBI40N-120, please download the datasheet in www.seekic.com or www.chinaicmart.com .
