Product Details

Description



Features:

High Output Current
       IO= 100 mA
Fixed Output Voltage
       VO= -5 V, -6 V, -8 V, -12 V, -15 V
Complementary Positive Regulators 78L00A Series
Available in either ±5% (AC) Selection



Specifications

Rating Symbol Value Unit
Input Voltage
Vo = -5 V to -9V
Vo = -12 V to -15V 		V1 -30
-35		 V
Output Current IO 100 mA
Maximum Power Dissipation
Case KT-26 (TO-92) Z Suffix
Case KT-47 (SOT-89) F Suffix
Case 4303.8-1 (SO-8) D Suffix		 PD 500
350
500		 mW
Junction Temperature TJMAX 150 °C
Operating Junction Temperature Range TOPR -30 to +85 °C
Storage Temperature Range TSTG -40 to +150 °C



Description

The 79L00A Series of three terminal negative voltage regulators is available with several fixed output voltages making them useful in a wide range of applications. These regulators are inexpensive, vise-to-use devices suitable for a multitude of applications that require a regulated supply of up to 100 mA. These regulators feature internal current limiting and thermal shutdown making them remarkably rugged. No external components are required with the 79L00A devices in many applications.

The 79L00A Series offer a substantial performance advantage over the traditional zener diode-resistor combination, as output impedance and quiescent current are substantionally reduced.

The voltages of the 79L00A Series available allow the 79L00A to be used in logic systems,instrumentation, HiFi, and other solid state electronic equipment.

The 79L00A Series is available in 3-Pin plastic package SOT54 (Z), 3-Pin mini power plastic package SOT89 (F) and the 8-Pin plastic package SO8 (D) offers superior quality and performance at low cost.
