7514B2-4

Color :
LED Size :
Body Shape :
Body Length :
Material :
Product : Light Pipe


Pinout




Specifications

Part Number: 7514B2-4
Serial Number: 7514
LED type: SMD LED
Type: Right Angle, 4 Wide
Mounting: PCB Press-In Pin
Works with: 7016X Series
Housing ul rating: UL 94-V2
RoHS Status: Yes


Description

Bright•Pipes™ Optical Lightpipes of the 7514B2-4 produce bright, even indication based on optical ray tracing. They conveniently and economically conduct light from SMT LEDs through angles and distances to a viewable front lense surface in order to provide an attractive, bright and even indication of equipment of function status with a minimal attenuation of light output through the optical fibers that join the base, at the LED light source, to the lens front.


Parameters:

Technical/Catalog Information	7514B2-4
Vendor	CML Innovative Technologies Inc
Category	Optoelectronics
Color	Clear
Mounting Type	PCB, Right Angle
Lens Style/Size	Round, 3mm, T-1
Configuration	4 wide
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	7514B2 4 7514B24 L71500 ND L71500ND L71500
