Features: · 1.2V to 3.6V VCC supply operation· 3.6V tolerant inputs and outputs· tPD 3.0 ns max for 3.0V to 3.6V VCC· Power-off high impedance inputs and outputs· Static Drive (IOH/IOL) ±24 mA @ 3.0V VCC· Uses patented Quiet Seriesä noise/EMI reduction circuitry· Latchup performance exceeds J...
74VCX16373: Features: · 1.2V to 3.6V VCC supply operation· 3.6V tolerant inputs and outputs· tPD 3.0 ns max for 3.0V to 3.6V VCC· Power-off high impedance inputs and outputs· Static Drive (IOH/IOL) ±24 mA @ 3.0...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
The 74VCX16373 contains sixteen non-inverting latches with 3-STATE outputs and is intended for bus oriented applications. The device is byte controlled. The flip-flops appear to be transparent to the data when the Latch Enable (LE) is HIGH. When LE is LOW, the data that meets the setup time is latched. Data appears on the bus when the Output Enable (OE) is LOW. When OE is HIGH, the outputs are in a high impedance state.
The 74VCX16373 is designed for low voltage (1.2V to 3.6V) VCC applications with I/O compatibility up to 3.6V.
The 74VCX16373 is fabricated with an advanced CMOS technology to achieve high speed operation while maintaining low CMOS power dissipation.
