Features: · 1.2V to 3.6V VCC supply operation· 3.6V tolerant inputs and outputs· tPD 3.3 ns max for 3.0V to 3.6V VCC 3.8 ns max for 2.3V to 2.7V VCC 7.6 ns max for 1.65V to 1.95V VCC· Power-off high impedance inputs and outputs· Supports live insertion and withdrawal (Note 1)· Static Drive (IOH/IO...
74VCX162240: Features: · 1.2V to 3.6V VCC supply operation· 3.6V tolerant inputs and outputs· tPD 3.3 ns max for 3.0V to 3.6V VCC 3.8 ns max for 2.3V to 2.7V VCC 7.6 ns max for 1.65V to 1.95V VCC· Power-off high...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Supply Voltage (VCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . -0.5V to +4.6V
DC Input Voltage (VI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.5V to +4.6V
Output Voltage (VO)
Outputs 3-STATED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.5V to +4.6V
Outputs Active (Note 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.5V to VCC + 0.5V
VCC = 0V . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . -0.5V to +4.6V
DC Input Diode Current (IIK)
VI < 0V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . -50 mA
DC Output Diode Current (IOK)
VO < 0V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . .-50 mA
VO > VCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +50 mA
DC Output Source/Sink Current (IOL/IOL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±50 mA
DC VCC or Ground Current per . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±100 mA
Supply Pin (ICC or Ground)
Storage Temperature Range (Tstg) . . . . . . . . . . . . . . . . . . . . . . . . .-65°C to +150°C
The 74VCX162240 contains sixteen inverting buffers with 3- STATE outputs to be employed as a memory and address driver, clock driver, or bus oriented transmitter/receiver.
The device is nibble (4-bit) controlled. Each nibble has separate 3-STATE control inputs which can be shorted together for full 16-bit operation.
The 74VCX162240 is designed for low voltage (1.65V to 3.6V) VCC applications with I/O capability up to 3.6V. The 74VCX162240 is also designed with 26W series resistors in the outputs. This design reduces line noise in applications such as memory address drivers, clock drivers, and bus transceivers/transmitters.
The 74VCX162240 is fabricated with an advanced CMOS technology to achieve high speed operation while maintaining low CMOS power dissipation.
