74ALVCH16244

Wide supply voltage range of 1.2V to 3.6V
Complies with JEDEC standard no. 8-1A
CMOS low power consumption
MULTIBYTE^tm flow-through standard pin-out architecture
Low inductance multiple V_cc  and GND pins for minimum noise and ground bounce
Direct interface with TTL levels
Bus hold on data inputs (74ALVCH16244 only)
Output drive capability 50 transmission lines @ 85
Current drive ±24 mA at 3.0 V

The 74ALVC16244(74ALVCH16244) is a 16-bit non-inverting buffer/line driver with 3-State outputs. The device can be used as four 4-bit buffers, two 8-bit buffers or one 16-bit buffer. The 3-State outputs are controlled by the output enable inputs 1OE  and 2OE  . A HIGH on nOE   causes the outputs to assume a high impedance OFF-state.
The 74ALVCH16244 has active bus hold circuitry which is provided to hold unused or floating data inputs at a valid logic level. This feature eliminates the need for external pull-up or pull-down resistors.
The 74ALVCH16244 has 5V tolerant inputs.
