74ALVC162244

    1.65V to 3.6V V_CC supply operation
    3.6V tolerant inputs and outputs
    26 series resistors in outputs
    t_PD
       3.8 ns max for 3.0V to 3.6V V_CC
       4.3 ns max for 2.3V to 2.7V V_CC
       7.6 ns max for 1.65V to 1.95V V_CC
    Power-off high impedance inputs and outputs
    Supports live insertion and withdrawal
    Uses patented noise/EMI reduction circuitry
    Latchup conforms to JEDEC JED78
    ESD performance:
        Human body model> 2000V
        Machine model > 200V
    Also packaged in plastic Fine-Pitch Ball Grid Array(FBGA)




    The 74ALVC162244 contains sixteen non-inverting buffers with 3-STATE outputs to be employed as a memory and address driver, clock driver, or bus oriented transmitter/receiver. The device is nibble (4-bit) controlled. Each nibble has separate 3-STATE control inputs which can be shorted together for full 16-bit operation.

  The 74ALVC162244 is designed for low voltage (1.65V to 3.6V) VCC applications with I/O capability up to 3.6V.

  The 74ALVC162244 is also designed with 26 series resistors in the outputs. This design reduces line noise in applica-tions such as memory address drivers, clock drivers, and bus transceivers/transmitters.
