74ACTQ16541

Utilizes Fairchild FACT Quiet Series technology
Guaranteed simultaneous switching noise level anddynamic threshold performance
Guaranteed pin-to-pin output skew
Separate control logic for each byte
16-bit version of the ACTQ541
Outputs source/sink 24 mA
Additional specs for Multiple Output Switching
Output loading specs for both 50 pF and 250 pF loads

Supply Voltage (V_CC)                   -0.5V to +7.0V
DC Input Diode Current (I_IK)
V_I = -0.5V                                               -20 mA
V_I = V_CC + 0.5V                                         +20 mA
DC Output Diode Current (I_OK)
V_O=  -0.5V                                               -20 mA
V_O= V_CC+ 0.5V                                           +20 mA
DC Output Voltage (V_O)         -0.5V to V_CC + 0.5V
DC Output Source/Sink Current (I_O )         ±50 mA
DC V_CC or Ground Current
per Output Pin                                          ±50 mA
Storage Temperature               -65°C to +150°C

The 74ACTQ16541 contains sixteen non-inverting bufferswith 3-STATE outputs designed to be employed as a mem-ory and address driver, clock driver, or bus oriented trans-mitter/receiver. The device is byte controlled. Each bytehas  separate 3-STATE control inputs which can be shortedtogether for full 16-bit operation.
The 74ACTQ16541 utilizes Fairchild Quiet Series(TM) technol-ogy to guarantee quiet output switching and improved dynamic threshold performance. FACT Quiet Series(TM) fea-tures GTO(TM) output control for superior performance.
