74ABT16541

*Power-up 3-State
*Multiple VCC and GND pins minimize switching noise
*Provides ideal interface and increases fan-out of MOSMicroprocessors
*3-State buffers sink 64mA and source 32mA
*74ABTH16541 incorporatebus-hold data inputs which eliminatethe need for external pull-up resistors  tohold unused inputs
*Latch-up protection exceeds 500mA per Jedec Std 17
*ESD protection exceeds 2000 V per MIL STD 883 Method 3015and 200 V per Machine Model
*Two 8-bit bus interfaces
*Bus-hold data inputs eliminate the need for external pull-upresistors to hold unused inputs

The 74ABT16541 high-performance BiCMOS device combines  lowstatic and dynamic power dissipation with highspeed and  highoutput drive.
The 74ABT16541 has two octal buffers that are ideal for driving buslines. The outputs are all capable of sinking 64mA and sourcing32mA.
Two options are available, 74ABT16541 which does not have thebus-hold feature and 74ABTH16541 which incorporates thebus-hold feature.
