72001-A8

Two sets of parallel/serial circuits supporting three modes: start-stop synchronization, character synchronization, and bit synchronization modes

Easy application to a system supporting two or more communication protocols such as a protocol converter or ISDN terminal adapter

DPLL (Digital Phase Locked Loop), baud rate generator, and crystal oscillation circuit for transmission/reception clock Helps reduce cost by decreasing the number of external circuits Many variations with power-saving features and small package size easy application to portable terminals and high-accuracy portable terminals

The features common to the µPD72001-11 and 72001-A8 are explained as the features of the MPSC in this
ocument.

The µPD72001-11 is an MPSC (Multi-Protocol Serial Controller) which is a general-purpose communication LSI equipped with two sets of bidirectional parallel/serial converter circuits for data communication.  This controller 72001-A8 has a transmitter function to convert the parallel data output by a data terminal into serial data and transmit this data to a data transmission system such as a modem, and a receiver function to convert the serial data output by the data transmission system into parallel data.

The MPSC 72001-A8 can be used with data communications equipment with a variety of communication modes such as the generally and widely used start-stop synchronization mode, and the HDLC mode which is used for high-speed communication.

The µPD72001-A8 is a low-voltage model.
For this product, the following documents are separately available.  Read these documents as well as this Data Sheet.
User's Manual (S12472E)
  (I) (S12753E)
Application Notes
  (II) (On preparation)
  (III) (On preparation)
