Supply Voltage
                                                                       36 Vdc or + 18 Vdc V+
Differential Input Voltage
(Note 5)
                                                                       36 Vdc
Input Voltage
                                                                       -0.3 Vdc to +36 Vdc
Input Current
(Note 6)
    (Vin < -0.3 Vdc)                                           50mA
Power Dissipation
(Note 2, 3)
   LCC                                                              1250mW
   CERDIP                                                         1200mW
   CERPACK                                                       680mW
   CERAMIC S.O.I.C.                                          680mW
Output Short-Circuit to GND
(Note 4)
                                                                         Continuous
Maximum Junction Temperature
                                                                         150 C
Storage Temperature Range
                                                                         -65 C to +150 C
Lead Temperature
      (Soldering, 10 seconds)                              260 C
Operating Temperature Range
                                                                          -55 C to +125 C
Thermal Resistance
ThetaJA
     LCC              (Still Air)                                    100 C/W
                    (500LF/Min Air flow)                        73 C/W
     CERDIP           (Still Air)                                 103 C/W
                     (500LF/Min Air flow)                       65 C/W
     CERPACK          (Still Air)                                183 C/W
                    (500LF/Min Air flow)                       120 C/W
     CERAMIC S.O.I.C. (Still Air)                            183 C/W
                    (500LF/Min Air flow)                       120 C/W
ThetaJC
    LCC                                                                28 C/W
    CERDIP                                                           23 C/W
    CERPACK                                                        23 C/W
    CERAMIC S.O.I.C.                                           23 C/W
ESD Tolerance
(Note 7)
                                                                          600V
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the device is functional, but do not guarantee specific performance limits. For guaranteed specifications and test conditions, see the Electrical Characteristics. The guaranteed specifications apply only for the test conditions listed. Some performance characteristics may degrade when the device is not operated under the listed test conditions.

Note 2: The maximum power dissipation must be derated at elevated temperatures and is dictated by Tjmax (maximum junction temperature), ThetaJA (package junction to ambient thermal resistance), and TA (ambient temperature). The maximum allowable power dissipation at any temperature is Pdmax  = (Tjmax - TA)/ThetaJA or the number given in the Absolute Maximum Ratings, whichever is lower.

Note 3: The low bias dissipation and the ON-OFF characteristic of the outputs keeps the chip dissipation very small (Pd < 100mW), provided the output transistors are allowed to saturate.

Note 4: Short circuits from the output to V+ can cause excessive heating and eventual destruction. When considering short circuit to ground, the maximum output current is approximately 20mA independent of the magnitude of V+.

Note 5: Positive excursions of input voltage may exceed the power supply level. As long as the other voltage remains within the common-mode range, the comparator will provide a proper output state. The low input voltage state must not be less than -3.0 Vdc (or 0.3 Vdc below the magnitude of the negative power supply, if used) (at 25 C).

Note 6: This input current will only exist when the voltage at any of the input leads is driven negative. It is due to the collector-base junction of the input PNP transistors becoming forward biased and thereby acting as input diode clamps. In addition to the diode action, there is also lateral NPN parasitic transistor action on the IC chip. This transistor action can cause the output voltages of the comparators to go to the V+ voltage level (or to ground for a large overdrive) for the time duration that an input is driven negative. This is not destructive and normal output states will re-establish when the input voltage, which was negative,again returns to a value greater than -0.3 Vdc (at 25 C).

Note 7: Human body model, 1.5K Ohms in series with 100pF.

The LM139A consists of four independent precision voltage comparators. These were designed specifically to operate from a single power supply over a wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. These comparators LM139A also have a unique characteristic in that the input common-mode voltage range includes ground,even though operated from a single power supply voltage.

Application areas of LM139A include limit comparators, simple analog to digital converters; pulse,squarewave and the time delay generators; wide range VCO; MOS clock timers; multivibrators and high voltage digital logic gates. The LM139A was designed to directly interface with TTL and CMOS. When operated from both plus and minus power supplies, LM139A will directly interface with MOS logic-where the low power drain of the LM139A is a distinct advantage over standard comparators.
