627

Model 627 is a a type of .220" small outline dual-in-line thick film DIP surface mount resistor.

There are some specufucations about 627.Standard Resistance Range, Ohms 10 to 1Meg (Plus "0 Ohm" Jumper)Standard Resistance Tolerance, at 25°C is ±2% (<33 Ohms = ±1Ohm)(Optional: F Tol. = ±1%).Operating Temperature Range is-55°C to +125°C.Temperature Coefficient of Resistance is±100ppm/°C (<100 Ohms = ±250ppm/°C).Temperature Coefficient of Resistance, Tracking is±50ppm/°C.Maximum Operating Voltage is50Vdc or PR.Insulation Resistance 10,000 Megohms.Thermal Shock plus Power Conditioning is R 0.70%.Short Time Overload is R 0.25%.Moisture Resistance is R 0.50%.Mechanical Shock is R 0.25%.Vibration is R 0.25%.Low Temperature Operation is R 0.25%.High Temperature Exposure is R 0.50%.Load Life, 2,000 Hours (33Ohms = ±0.5 Ohm) isR 0.50%.Resistance to Solder Heat (Total immersion in solder at 280°C for 10 sec.)is R 0.25%.Dielectric Withstanding Voltage is 200V for 1 minute.Temperature Exposure, Maximum is 215°C for 3 minutes.

Well, this is a simple introduction to this type of product, if you want to know more about 627, please pay more attention to our web. Thanks for your attention!
